Product Type:
Switchable MM/MC phono stage with MC load adjustment
Audio Outputs:
Max output signal: 8 Vrms
Headroom:
MM: 22dB ref 5mV input
MC (low & high gain): 23dB ref 0.5mV input low gain setting, 17dB ref 0.5mV high gain setting
Audio Inputs:
MM: (Partial) – 2dB at 20Hz and -3dB at 14Hz
Audio-Eingänge
Endstufeneingang:
+/-18V DC @300mA
Audio-Ausgänge
Stromversorgung:
Stereo RCA
Crosstalk:
MM: >75 dB
THD + N:
MM: <0.005% ref 50mV input
MC (low & high gain): <0.005% ref 1.5mV input
Signal-to-Noise Ratio:
MM: 83dB réf. 5 mV A-wtd
MC (low & high gain): 84dB ref 0.5mV A-wtd (both gain settings)
Gain:
MM: 42dB
MC (low & high gain): 61dB low gain and 67dB high gain (switchable)
Phono Specific
RIAA Accuracy:
MM: +/-0.1dB
Physische Daten
Gewicht:
3.4kg
Abmessungen (H x B x T):
23/4x 83/8x 121/2" (7x21.4x31.7cm)
Stromversorgung
Ausgangsleistung:
1 x Stereo RCA
1 x 5 pin DIN
1 x 8 pin DIN
Power Output:
MM: 47kΩ and 100pF
MC (low & high gain):
16 selectable resistive values:
1 000 Ω, 600 Ω, 430 Ω, 330 Ω, 250 Ω,
215 Ω, 185 Ω,165 Ω,150 Ω, 140 Ω, 125 Ω,
115 Ω, 105 Ω, 100 Ω, 90 Ω, 85 Ω
16 selectable capacitive values:
100 pF, 400 pF, 700 pF, 1000 pF,
1300 pF, 1600 pF, 1900 pF, 2200 pF,
2500 pF, 2700 pF, 3100 pF, 3400 pF,
3700 pF, 4000 pF, 4300 pF, 4600 pF
Upgrades
Power Supply :
Type 1
