Dynavector ASKA – MC phono cartridge for natural and detailed analog sound

The Dynavector ASKA is a high-quality MC (Moving Coil) phono cartridge that provides an uncomplicated entry into the fascinating world of MC cartridges. As Dynavector’s entry-level model, the ASKA combines the Japanese manufacturer's many years of experience with a meticulously tuned design and particularly natural, open, and low-distortion music reproduction.

The Dynavector ASKA was developed to make the characteristic benefits of moving coil technology accessible to a wide circle of vinyl enthusiasts. The low moving mass of an MC system enables precise and fast signal transmission, clear spatial imaging, and convincing dynamics and detail.

It utilizes a powerful neodymium magnet in combination with Dynavector’s special softened-magnet technology. This design was developed to reduce unwanted distortion and harsh, intrusive sonic artifacts while simultaneously allowing for high output and clean channel separation.

Another feature of the Dynavector ASKA is the specially treated pure iron magnetic circuit. The magnetic properties are optimized through a controlled annealing process. The result is an expansive and natural soundstage with high resolution and precise spatial imaging.

The ASKA is equipped with an elliptical diamond stylus. This balanced profile allows for the precise tracking of fine musical details while offering easy integration into a variety of turntable and tonearm combinations.

Dynavector offers the ASKA in two versions to accommodate different phono preamplifiers and system configurations:

ASKA-H – High Output MC:
With an output voltage of 2.8 mV, the ASKA-H can be operated directly via a classic MM phono input at 47 kΩ. This makes it particularly suitable for vinyl listeners who want to upgrade from an MM cartridge to the sonic characteristics of an MC system without necessarily needing a separate MC phono input or step-up transformer.

ASKA-L – Low Output MC:
The low-output version delivers 0.3 mV and is designed for operation with an MC phono input or a matching step-up transformer (SUT). The ASKA-L version offers an especially authentic experience of the typical characteristics of a classic low-output MC system.

Both versions are manufactured in Japan, hand-assembled, and individually tested. The housing features integrated M2.5 threaded holes, making mounting on a headshell or tonearm particularly simple and convenient.

The Dynavector ASKA MC phono cartridge is therefore an excellent choice for discerning vinyl lovers who are looking for a natural, open, and dynamic analog sound and who value the traditional Japanese manufacturing quality of Dynavector.

Type:
Moving Coil (MC) Cartridge

Variants:
ASKA-H High Output / ASKA-L Low Output

Magnet:
Neodymium

Magnet Technology:
Softened Magnet / Softened Magnetism

Magnetic Circuit:
Pure iron with special heat treatment (annealing)

Stylus:
Elliptical

Cantilever:
Hardened aluminum pipe, 6 mm length

Frequency Response:
20 Hz – 20 kHz (±2 dB)

Channel Separation:
25 dB at 1 kHz

Channel Balance:
1.0 dB at 1 kHz

Compliance:
12 mm/N

Recommended Tracking Force:
1.8 – 2.2 g

Weight:
5.8 g

Mounting:
Integrated M2.5 threaded holes

Manufacturing:
Japan

Assembly:
Hand-assembled and individual quality control

Dynavector
ASKA-H – High Output

Output Voltage:
2.8 mV at 1 kHz / 5 cm/s

Internal Impedance:
150 ohms

Recommended Load Impedance:
over 1,000 ohms

Compatibility:
MM phono input with 47 kΩ possible

Especially suitable for:
Users looking to upgrade from MM to MC

Dynavector ASKA-L – Low Output

Output Voltage:
0.3 mV at 1 kHz / 5 cm/s

Internal Impedance:
5 ohms

Recommended Load Impedance:
over 30 ohms

Compatibility:
MC phono input or suitable MC transformer

Especially suitable for:
Classic MC phono stages and high-quality analog turntables
