Since 2004, the Linear has been allowing all common headphones to perform at their absolute peak. Our top model is trusted by the most demanding users, from Westdeutscher Rundfunk and the audiophile label TACET to headphone specialists like Sennheiser and AKG. It is not without reason that the Linear is considered the reference class of its genre.

When you put on your headphones and play your favorite CD, the Linear lets wonderful worlds emerge before your mind's eye. Physical, rich bass and delicate resolution unfold your favorite tracks in their full splendor across the entire frequency spectrum. Carefully selected components and a highly sophisticated circuit architecture form the foundation of this industry leader.

"The best transistor headphone amp that audio knows."
— audio

Masterful in every situation

Always keeping your needs in mind, its three gain settings allow for an impressive listening experience – with a wide variety of headphones and a diverse range of audio sources. Naturally, we have taken into account the differing power requirements and efficiencies of the headphone types available on the market.

If you would like to share the joy of this quality of music reproduction with family and friends: our multiple award-winning model is happy to drive two headphones simultaneously. Of course, the listening experience remains identically fabulous. The two parallel outputs of the discrete Class A transistor output stage serve as the basis for this dual musical enjoyment.

By the way, the Linear also brings your active speakers to astonishing vitality, should you wish. Fabulous sound in every situation, always striving for perfection – that is our Linear.

Input impedance
47 kOhm

Maximum gain
0 dB, 10 dB, 18 dB, 20 dB selectable via DIP switch

Frequency response
10 Hz (-0.3 dB) to 35 kHz (-1 dB)

Signal-to-noise ratio
> 95 dB at 0 dB gain

THD
< 0.001 % at 6 mW/300 Ohm

Channel separation
> 70 dB at 10 kHz

Output power
400 mW/60 Ohm
200 mW/300 Ohm

Output impedance
Pre-Out 50 Ohm
Phones Out 5 Ohm

Audio connections
Neutrik headphone jacks with gold-plated contacts
1 x Pre-Out
2 x Phones Out
gold-plated RCA jacks with Teflon insulation

Mains voltage
240 V AC

Fuse
250 mA T

Power consumption
10 W

Dimensions W x D x H
110 mm x 280 mm x 50 mm

Weight
1.5 kg net
