Lotoo PAW S2 – Compact USB-DAC with High-Res sound for smartphone and PC

The Lotoo PAW S2 is a high-quality USB-DAC and headphone amplifier that offers audiophile sound quality in an exceptionally compact format. As the successor to the successful PAW S1, the PAW S2 has been further developed in all key areas and impresses with higher performance, improved sound, and comprehensive compatibility for Android, iOS, Windows, and macOS. Whether at home, in the office, or on the go – the PAW S2 turns your smartphone, tablet, or computer into a powerful HiFi source.

High-Res audio and powerful headphone amplifier

Despite its compact design, the Lotoo PAW S2 delivers an impressive output power of up to 150 mW, reliably driving even more demanding headphones. The precise digital-to-analog conversion ensures detailed, dynamic, and natural music reproduction with high resolution and excellent channel separation – ideal for music lovers who do not want to compromise, even while on the move.

MQA support for studio-quality streaming

The PAW S2 supports MQA (Master Quality Authenticated) and enables up to 4x MQA unfolding directly in the device. This allows users of streaming services like TIDAL to enjoy music in high-resolution studio quality – without the need for an additional DAC or software.

Maximum compatibility with minimal power consumption

The Lotoo PAW S2 can be connected directly to Android smartphones, tablets, PCs, and Macs via USB-C. For Apple devices, only a Lightning to USB-C cable is required. Despite its high performance, the DAC is extremely energy-efficient and places minimal strain on the mobile device's battery – perfect for long listening sessions on the go.

High-quality aluminum housing for mobile use

The robust aluminum housing reliably protects the high-end technology and gives the PAW S2 a sophisticated look. Thanks to its compact dimensions, the USB-DAC fits easily into any bag and is the ideal companion for discerning HiFi fans who want to enjoy their music in the best quality at any time.

Highlights of the Lotoo PAW S2

• Compact high-end USB-DAC and headphone amplifier

• Significantly improved successor to the popular PAW S1

• High-resolution music playback for Android, iOS, Windows, and macOS

• Up to 150 mW output power for demanding headphones

• MQA support with up to 4x MQA unfolding

• Very low power consumption for extended mobile use

• Robust and high-quality aluminum housing

• USB-C connection for fast and simple connectivity

• Ideal for HiFi streaming, music lovers, and mobile high-end audio

Technical details:

- Supported audio formats: PCM up to 384 kHz / 32-bit, DSD up to DSD128, MQA up to 4x unfold
- PCM sampling rate: 32 Hz to 384 kHz / 32-bit
- DSD support: up to DSD128
- MQA support: up to 4x MQA unfold
- Headphone outputs: 3.5 mm (unbalanced), 4.4 mm (balanced)
- Output power 3.5 mm: 125 mW per channel at 32 ohms
- Output power 4.4 mm: 150 mW per channel at 32 ohms
- Line-out 3.5 mm: 2.34 Vrms
- Line-out 4.4 mm: 2.55 Vrms
- Signal-to-noise ratio: 123 dB (3.5 mm), 123 dB (4.4 mm)
- Frequency response 3.5 mm: 20 Hz to 20 kHz (+/- 0.017 dB)
- Frequency response 4.4 mm: 20 Hz to 20 kHz (+/- 0.016 dB)
- THD+N: 0.0003 percent (-109 dB)
- USB connection: USB-C
- Display: OLED, 128 x 32 pixels
- Firmware updates: via USB
- Operating system: LTOS
- Dimensions: 66 x 22 x 13 mm
- Weight: 29 g
