Universal & future-proof: High-end preamplifier, D/A converter, headphone amplifier!

The Pre Box RS Digital combines all the features of the DAC Box RS with a highly linear preamplifier that features a switchable output stage using solid-state and tube technology. As in all of our top-class digital products, we use PCM1792 DACs, which are used here in dual-differential mode for ultimate sound fidelity. As a unique feature, you can alternatively switch to a 32bit/384kHz converter chip, also from Texas Instruments. The high-quality headphone amplifier, which is also included, features a switchable output impedance to enable optimal matching with any pair of headphones. The Pre Box RS Digital offers 3-dimensional soundstage, perfect micro-dynamic reproduction, and ultimate resolution, with the option to connect a variety of digital sources and one analog source. The Pre Box RS Digital shows its true qualities, especially in combination with the Pro-Ject CD Box RS transport, as a specially designed I²S interface (via RJ45) ensures maximum jitter-free playback.

D/A converter:
DAC1 – 2 x PCM1792 24bits/192kHz; DAC2 – PCM5102 32bits/384kHz

Tubes:
2 x 6922 EH

Digital inputs:
1 x USB 2.0 Audio 32/384 + DoP-DSD 64/128
1 x RJ45 Sonic I2S for CD Box RS in Sonic Mode
2 x S/PDIF 24/192
4 x S/PDIF Optical 24/96
1 x AES/EBU balanced 24/192

Line input:
1 pair of RCA jacks

Input impedance:
33 kOhm

Analog output:
Pre-out (XLR & RCA), headphones (6.35mm jack)

Headphone impedance:
5 / 20 / 50 ohms switchable

Analog input sensitivity:
1.6V RMS for full headphone volume

Frequency range:
20Hz - 50kHz (+ 0dB/- 0.1 dB)

Signal-to-noise ratio:
-100dB (IEC-A)

THD:
0.005% transistor output / 0.25% tube output

Master clock output:
16.9344MHz for CD Box RS in Sonic Mode

Power supply:
20V/3A DC suitable for worldwide use

Power consumption:
300mA transistor / 850mA tube / 90mA standby

Dimensions W x H x D:
206 x 72 x 210mm, including jacks

Weight:
1950 g without power supply
