High-efficiency performance in the 8-channel Rotel C8+ Class-AB multi-channel amplifier with excellent sound quality, featuring 150 W per channel or 300 W bridged at 4 ohms using proprietary Rotel amplifier technology.

The oversized, in-house manufactured toroidal transformer powers 32 output devices for effortless, controlled bass reproduction.

Maximum installation flexibility thanks to 4 analog and 4 digital inputs that can be routed to all zones. Front display and controls for source selection and individual adjustment of volume, bass, and treble for each channel.

IP and RS232 interfaces as well as 12V triggers for integration into control systems.

2U chassis requires no top or bottom clearance for rack mounting.

INTERMODULATION DISTORTION (60Hz:7kHz, 4:1)
<0.1%

DAMPING FACTOR (20Hz - 20kHz, 8Ω)
80

TONE CONTROLS
± 10dB at 100Hz / 10kHz

CROSSTALK/SEPARATION
>50dB

DIGITAL TO ANALOG CONVERTER
Texas Instruments

INPUT SENSITIVITY
Line Level Inputs: 0.43V
Digital Inputs: -13.5dBfs

INPUT IMPEDANCE
Line Level Inputs: 31kΩ
Digital Inputs: 75Ω

INPUT OVERLOAD
Line Level Inputs (RCA): 2.8V

DIGITAL SIGNALS (COAXIAL/OPTICAL)
SPDIF LPCM (up to 192kHz/24-bit)
