The CD14MKII delivers precise CD playback with impressive clarity that resolves even the finest details. The 32-bit Texas Instruments D/A converter features an independent power supply to isolate the motor control from the sensitive audio circuits, thereby reducing noise and distortion. The CD14MKII brings out the best in your CD collection.

The CD14MKII continues Rotel's tradition of award-winning CD players, featuring power supply innovations and re-tuned acoustic components for more precise audio signal reproduction with rich detail.

Critical digital-to-analog conversion is handled by a premium 32-bit D/A converter from Texas Instruments with an independent power supply to eliminate unwanted distortion, isolate the motor control from the sensitive audio circuits, and reduce noise and distortion.

The tray-loading mechanism, IR remote control, front-panel controls, and graphical display ensure effortless operation.

Bring your own CDs and let the CD14MKII show you the impressive detail, clarity, and precision with which it reproduces your music.

POWER SUPPLY
230V, 50Hz

POWER CONSUMPTION
15W

STANDBY POWER CONSUMPTION
<0.5W

TOTAL HARMONIC DISTORTION
0.0035% @ 1kHz

FREQUENCY RESPONSE
20Hz - 20kHz ±0.5dB

SIGNAL-TO-NOISE RATIO (IHF A)
>118dB

DYNAMIC RANGE
>99dB

D/A CONVERTER
Texas Instruments

CHANNEL BALANCE
±0.5dB

CHANNEL SEPARATION
>118dB @ 10kHz

INTERMODULATION DISTORTION
0.0035% @ 1kHz

PHASE LINEARITY
±0.5 degree

DIGITAL OUTPUT
0.5V, peak to peak

OUTPUT IMPEDANCE
100Ω

LOAD IMPEDANCE
75Ω

DIMENSIONS (W × H × D)
430 × 98 × 314mm
17" × 3.8" × 12.3"

FRONT PANEL HEIGHT
80mm
(3.15")

NET WEIGHT
6.51kg (14.35lbs.)
