- Tubes used 2 x 12AX7, 1 x 12AU7, 1 x 6SN7

- ZERO FEEDBACK - no feedback for the best dynamics and musicality

- Full utilization of the output transformer for emotional and musical sound

- 4-input phono selector is convenient for listeners who have many turntables, many tonearms, or cartridges and want to switch quickly.

- There are 2 modes for volume control and bypass, so that users can conveniently combine their audio equipment. The P10 can be connected directly to a power amplifier (using the P10's volume control) or an integrated amplifier (using bypass volume - setting the MAX output on the P10 and controlling the volume on the integrated amplifier).

- Step-up transformer for MC available

Inputs:
4 x RCA MM RIAA Phono

Tubes:
- Output tubes: 1 x 6SN7 Single Ended output Transformer
- Pre & driver tubes: 2 x 12AX7 ; 1 x 12AU7

Frequency response:
20 Hz - 20 kHz (+/- 1dB)

Input sensitivity:
2.5mV

Input impedance:
47 kOhm

Output voltage:
Max. 30Vp-p

Mains voltage:
- Vietnam: 220V
- European version: 230V
- Other countries: it is possible to set 100/110/117/240V/50-60Hz by
different markets.

Power consumption:
30W (ON) 0W (OFF)

Dimensions (W x D x H):
Approx. 45 x 38 x 14 (cm)

Weight (kg):
Approx. 16 kg

Shipping weight (kg):
Approx. 19 kg, depending on packaging

Warm-up time:
Approx. 5 minutes, after the break-in period

Break-in period:
Approx. 200 hours of music playback

Finish:
High-quality plywood chassis with natural rosewood veneer

Special feature:
Volume control can be switched off

Accessories:
1x Power cord
